OVERVIEW
Nippon Paint Marine's solutions offers long lasting coatings protection for your yacht collection.
Our products offers one of the longest lasting coating protections for your investments and maintaining constant lustre of the yacht's coatings. Nippon Paint Marine's products allows your crew or coating experts to apply it easily on your yacht.
YACHT COATING FEATURES
Excellent protection from fouling
Unlike most ocean-going and domestic vessels, yacht and powerboat owners have limited access to their vessels. Often, out of season, they remain moored for months at a time. Even if you don’t operate your boat at all for a few months, the Mariart series will protect your boat from fouling.
Easy application
You don’t have to be a professional painter. If you apply the right volume of paint in the right way, you can easily do DIY with your friends and family. Just make sure you have the appropriate quantity of Mariart Series paint and painting tools!
Innovation
Since the launch of “Mariart AF” in 2005, we have been constantly improving Mariart antifouling paints by repeatedly testing their performance at various marinas throughout Japan and at Nippon Paint Marine’s laboratories. On the other hand, our hull paints, which give a beautiful finish to boats, are always ready to be mixed and matched to the colour of the owner’s preference. Our development of totally balanced products that take workability, efficiency, economy, and safety into consideration will continue to ensure an enjoyable yacht/boat life for our customers.
Products for Yacht
Bottom ship paint
| Paint for boats and yachts | Ship Material | Degree of pollution in the water area used | |||||
| FRP | Wood | Aluminium | High | Low | Fresh water area* | ||
 | MARIART AF
White is light gray when painted, but changes to white after submersion. |  | |  | | | |
 | Cruiser Rainbow
| | | |  | | |
 | MASSIVE NEO
| | | | | | |
* A fresh water area is a water area such as a river with little (or no seawater) seawater.
** Depending on the application and purpose, powerboat paint can also be used for boats and yachts. Please contact us for more information.
| For propeller alloys | Type | Capacity | |||||
 | MARIART X NEO
| High hardness type | 500g | ||||
 | MARIART X NEO AEROSOL
| High hardness type | 300 ml (paint: 100 ml) | ||||
 | Tommy’s Propeller Kit
| Super water repellent antifouling coating system | 1 box | ||||
Primer
| Product Name | Type | ||||||
 | MARIART P 100
| Primer & Binder Coat Capacity: 4 kg | |||||
 | MARIART P 200
| Two-component epoxy universal primer Capacity: 4 kg set | |||||
Hull Paint
| Product Name | Type | ||||||
 | MARIART F 100
| One-component topcoat of special acrylic resin. Capacity: 1 kg | |||||
 | MARIART F 200
| Two-component polyurethane topcoat. Capacity: 1 kg set | |||||
Thinners
| Product Name | Applicable Paints | ||||
MARIART AF thinner | MARIART Ship bottom paint MARIART F100 Capacity: 1L | ||||
MARIART E thinner | MARIART P200 Capacity: 1L | ||||
MARIART U thinner | MARIART F200 Capacity: 1L |
Flow Rust Remover
| Product Name | Type | |||||
 | MARIART Miracle Remover Neo | Flow rust generated on the paint film can be easily removed without causing gloss. In addition to flow rust, yellowing of the FRP surface and dirt adhering to the propeller shaft can be easily removed. Capacity: 20Kg, 1Kg: Light yellow water-soluble liquid (strongly acidic PH2.0-2.5) | ||||
MARIART AF
A Top Lank Self Polishing Paint, Offering Sustained and Excellent Performance
• Suitable for FRP, Wood Boat
•Ideal for season long protection due to constant and stable elution
MASSIVE
A Copper-free Hard Antifouling Paint, Providing Consistent Protection for Power Boats Punching at High Speed
• Suitable for FRP, Aluminium, and Light Alloy Boat
• The Fully Dried Paint Film Surface can be Further Smoothen by Sanding with Sandpaper
MARIART P100
A Primer to Ensure Adhesion between the Gelcoat and an AF Paint & a Hull Paint
• Suitable for Above and Below the Waterline
• For FRP only
• Available as a Binder Coat
TOMMY'S PROPELLER KIT
A Complete Set of Everything Needed for Propeller Antifouling Painting
• Primer, Antifouling Paint, Each Thinners and Brush Provided
SUPPORT
Frequently asked questions
"I'm in trouble!" "What should I do?" We will answer the questions you have received.
ABOUT SHIP BOTTOM PAINT
In general, it is difficult to produce complete “pure white” with paint, and the “white” of ship bottom paint is slightly tinted.
For example, the cruiser rainbow “white” is strictly “milky white”, which is a little darker than white like drawing paper. In the case of MARIART’s “white”, it is gray when painted due to the copper contained in the antifouling agent, but it becomes somewhat white when soaked in water.
The fact that wasabi is effective in preventing marine deposits is actually the result of research by Nippon Paint Marine.
However, if you only need to add wasabi, there should be a paint that contains wasabi from the beginning. However, there is currently no such paint. This is because it is difficult to commercialise it due to the problems of maintaining antifouling power for a long period of time, paint price, and insufficient adhesion between paint films. For that reason, we do not recommend adding wasabi to the paint.
This is a phenomenon that occurs in areas where hedro is accumulated on the seabed. Hydrogen sulfide emitted from the seabed reacts with cuprous oxide contained in the ship’s bottom paint to form copper sulfide, which causes blackening. Hedro tends to accumulate in places where there is no or little tide in the city where domestic wastewater tends to accumulate, so as you asked, it can be said that it is a phenomenon that often occurs in some areas.
If it turns black, the antifouling effect of the ship bottom paint will be lost, so it is best to apply a paint that does not contain cuprous oxide (eg Cruiser Rainbow) to the ship bottom paint.
Alternatively, you can wipe it with thinner and repaint it, or if the area is heavily polluted, increase the number of coats.
If you put the special thinner on the surface of the paint and store it with the lid completely closed, it can be used for about 12 months. When using it again, stir it well from the bottom of the can before using it.
If it is the same manufacturer and the same product name, it is generally possible, but in that case, please consult the manufacturer.
CHOOSING THE SUITABLE PAINT
There are two types of ship bottom paint: a self-consumable type that prevents the adhesion of animals and plants while the coating film itself dissolves when it is submerged in water, and a high hardness type that prevents the adhesion of animals and plants by seeping the antifouling agent between the coating films.
Consumable paints are very effective for yacht mooring at sea (for antifouling properties). The high hardness type cannot take advantage of it. Since high-hardness type paint does not dissolve, unnecessary paint film tends to remain, and it is necessary to remove the previous paint with a ship bottom paint remover every time it is applied or every few years.
The advantages of using high hardness paint are power boats that always run at 30 knots or more, racing yachts, diving boats, etc.
Currently, most ship bottom paints contain cuprous oxide as an antifouling agent, but when they come into contact with metal parts, they do cause electrolytic corrosion.
There are also ship bottom paints that do not contain cuprous oxide (cruiser rainbow and MASSIVE), but these have less zinc reduction, but their antifouling properties are slightly lower than those of copper oxide-based paints. Besides, it can be said that zinc protects against electrolytic corrosion, so it is natural that zinc decreases.
Depending on the product, the type of antifouling agent may be different for each colour in order to maintain the hue.
Currently, the mainstream antifouling agent for ship bottom paint is red copper oxide, so it is easy to use for red paint, and it can be said that it is easy to give strong antifouling property to red paint.
If the bottom paint is exposed to the air for too long (eg, 3-4 months or more), the paint’s performance may deteriorate or the painted surface may crack.
From this point of view, especially from the viewpoint of aesthetics, we recommend paints that do not dissolve (Massive) rather than paints that dissolve on land (such as Mariart AF).
PAINTING
The surface of the FRP surface, which was shiny at the time of the new boat, will gradually deteriorate over the course of 5 to 10 years. “Hull paint” and “Outer panel paint (Mariart F100, F200)” are used to remake it cleanly.
For land storage, apply this “outer panel paint” to the entire surface including the bottom of the ship. At this time, if any paint on the bottom of the ship remains, remove all the paint and then apply the “outer panel paint”.
If you are mooring at sea, paint the bottom of the ship and paint the hull with “outer panel paint”.
Note: If the “outer panel paint” inadvertently adheres to the painted surface of the bottom of the ship, the antifouling effect will be reduced, so be sure to guard it properly with a vinyl sheet or newspaper before painting.
For meltable types such as “MARIART AF” and “Cruiser Rainbow”, applying 3 times will make the paint film thicker and will last longer. However, please be sure to observe the amount to be applied at one time and the drying time for each application.
On the other hand, with insoluble paints such as Massive, the antifouling effect is limited, so there seems to be little difference between two coats and three coats.
However, when painting the bottom of a ship, the “film thickness” is important, not the “number of coats”, so be sure to apply the specified amount even if the number of coats increases a little.
In the case of ship bottom paint, it depends on the thickness applied at one time, but the thicker the paint film, the easier it is to peel off. This is especially true for high hardness paints.
If the paint film peels off and the surface becomes rough, the speed will be adversely affected. It is recommended to remove the old paint with a ship bottom remover, sanding, etc. every 4 to 5 years.
It is most effective to apply it one month before the breeding season of barnacles and green algae (see the breeding season table here).
Specifically, we recommend around May to June for measures against animals such as barnacles, and around September to October for measures against plants such as green algae and slime. In addition, since the paint does not like the humidity caused by rain and the paint film does not dry easily during the rainy season, it is appropriate to avoid the rainy season and apply the first paint around May and the second paint around October.
When painting a new boat, or when removing all the old paint film or repainting, be sure to roughen the FRP substrate with paper before painting the bottom of the boat. The paint on the bottom of the ship will adhere more easily. Applying a primer will make it easier to adhere.
Also, if there is a part that comes off when repainting, be sure to completely remove that part with a scraper or the like.
Wear hats, goggles, gas masks, gloves, etc. as needed.
ABOUT OTHER PAINTS
Apply the rust preventive primer “MARIART P 200” to the undercoat. The recommended number of coats is 4 times. To prevent rust on metal parts, apply the undercoat firmly and repeatedly. The more times you paint, the longer the effect of the topcoat bottom paint will last.
Moisture has entered the bottom of the FRP due to long-term mooring. Blisters are also called “blisters”. The phenomenon of blister formation is called “osmosis”. We will inform you of the measures against osmosis separately. Please contact us if you wish.
Commercially available set nets and “antifouling paints for fishing nets” for aquaculture nets are effective.
That is Nippon Paint’s “Nippe Amitaro”. Please contact us for details.
OTHERS
Basically, when repainting, you need to pay for the ship’s uplift plus the cost of the MARIART paint.
If you ask a contractor, the painting fee will be on.
However, prices vary depending on the vendor and mooring location, so please contact a contractor for details. When leaving it for the first time, it is recommended to check the paint type / amount used / duration of effect.
As a first aid, wash your eyes with plenty of water and see a specialist.
The same applies not only to the bottom paint but also to other paints and thinners, so when painting, wear goggles, hats, military hands, masks, etc. for safety, and the paints and thinners may get in your eyes or come into direct contact with your skin. Please be careful not to do it.
Wash the brush with the special thinner of the paint used, and when the brush is sufficiently loosened, dry it and store it. Dispose of paint cans as industrial waste.
